3-Axle 40ftContainer Shipping Skeleton Semi Trailer Gooseneck Design
This heavy-duty semi-trailer combines a gooseneck design with a 3-axle skeletal frame, optimized for 40ft container transport with superior maneuverability and load distribution.
Key Features:
✔ 3-Axle Stability - Enhanced weight distribution for 60T+ loads
✔ Gooseneck Design - Improved turning radius & road compliance
✔ 40ft Skeleton Frame - Lightweight yet durable container chassis
✔ Low Deck Height (1,250mm) - Faster loading/unloading
✔ Twist Lock System - Secure ISO container fastening
Technical Advantages:
• High-tensile steel construction (Grade T700)
• Compatible with 20ft/40ft/45ft containers
• Optional air suspension/ABS brakes
• Corrosion-resistant paint system
Why Choose This Trailer?
→ 15% better fuel efficiency vs standard designs
→ 20% tighter turning capability (gooseneck advantage)
→ 10-year structural warranty
Best For:
Port and intermodal operations
Heavy container logistics
Oversized equipment transport
*Custom options available:
Extended gooseneck configurations
Telematics-ready models
Specialized brake systems*
5.0
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-1(units):10(days),2-10(units):21(days),11-25(units):45(days),>25(units):To be negotiated(days)
Customization:
Customized logo (Min. Order: 1 sets),Customized packaging (Min. Order: 1 sets),Graphic customization (Min. Order: 1 sets)
Brand Name:
LUYI VEHICLE
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Main Beam
T700/Q345 Steel
Function
Transport 20ft 40ft Container
Suspension
Mechanical Suspension
Color
Customers Optional
Axle
13/16 Ton Fuwa/BPW
Product name
3-axle Semi-trailer
Place of Origin
Shandong, China
Max Payload
60T
Size
12500*2500*1500mm
Material
Steel
Type
Semi-Trailer
Use
Truck Trailer
Brake
Duel Line Brake System
Keywords
20 Ft 40 Ft Container
King pin
2"(50mm)or3.5"(90mm) JOST
Landing Gear
Standard 28Ton
40ft Chassis Skeleton Interlink Trailer Tandem Dock Container Semi-trailer Skeleton Semi Truck Trailer
Products Description
Dimension | 12,500*2450*1450mm(According to customer demand) |
playload | 40,000kg |
Tare weight | 65,000kg |
Tyre | 12R22.5/11R22.5/13R22.5/11.00R20/12.00R20(specificationcan be Optional) |
Rim | 8.00-20/8.5-20/8.8-20 (Patent of electrophoretic paint) |
King pin | JOST brand 2.0 or 3.5 inch bolts type or Welding type |
Main beam | Height: 450mm-520mm, upper plate thickness is 14mm-25mm, middle plate thickness is 8mm-12mm, down plate thickness is 16mm-25mm; Material is Q345 Carbon Steel. |
Axle | 13ton*3 axle FUWA/BPW/Fuhua brand |
Light | Tail lamp with turn signal, brake light & reflector, side lamp etc |
Tool box | 1set standard tool box( waterproof type) |
Spare wheel carrier | 1 pieces( Patent type) |
Accessory | A set of tools,An instruction manual |
ABS system | optional |
Color | According to customer demand |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Product Display
Details Images
Product packaging
Company Profile
Luyi Vehicle has a first-class CNC cutting machine, automatic welding machine; Large bending machine, jigsaw machine, can machine, tank automatic welding turning machine, whole car through shot blasting machine, Swiss four-wheel positioning and other production and various testing equipment.
Why Choose Us
2. Technical Support by phone Whatsapp or email around the clock
3.Lifelong Parts Supports
4.The good faith management is our philosophy, and welcome visits our company at any time
5.According to your order, we provide suitable trailer.
6.We also provide rational packing and shipping program , let shipment save money and
security.
security.
Just trust us, you will get a satisfactory answer.
