500ton Concrete Beam Bridge Trailer | LUYI
This professional-grade Bridge Girder Transport Trailer combines heavy-duty engineering with intelligent design for infrastructure development projects. The trailer's modular hydraulic system allows customizable configurations to accommodate various beam lengths (up to 50m) and weights (500-ton capacity). Key technical features include:
Multi-axle synchronized steering for tight maneuverability
Load-distributing suspension to prevent concrete stress
Remote-controlled hydraulic functions for precise loading/unloading
Reinforced steel construction with anti-corrosion treatment
Adaptive braking system for heavy load control
5.0
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-1(units):10(days),2-10(units):21(days),11-25(units):45(days),>25(units):To be negotiated(days)
Customization:
Customized logo (Min. Order: 1 sets),Customized packaging (Min. Order: 1 sets),Graphic customization (Min. Order: 1 sets)
Brand Name:
Luyi
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Condition
Brand-new
Brake System
Dual Line Braking System
Color
Customers Optional
Axle
13T 16T 20 ton
Tire
12.00R22.5 /12R20 /315/80R22.5
Product name
Beam Bridge Dolly Trailer
Place of Origin
Shandong, China
Max Payload
>30000 kg
Size
14000mm-16000mm x 3000-3500mm x 1650 mm
Material
Steel
Type
Semi-Trailer
Use
Truck Trailer
Load weight
60 ton
Suspension System
Mechanical Spring
Application
heavy loads , excavators , construction machines
Landing Gear
Standard 28Ton
Products Description
Beam Bridge Dolly Trailer is a multiple axle rubber wheeled dolly use to deliver full span bridge beam with loading capacity up to 900 ton and a maximum length up to 36m.This remarkable giant machine was extensively used for the construction of few thousands km of high speed railway bridges, and designed for transporting precast full span girder, pre-cast segment, steel girder or other structures.
Product Paramenters
We can design and manufacture lowbed semi trailer according to your exact requirements, the following specifications for your reference.
Dimensions | 5000*2500*(700mm-1200mm) (According to customer demand) |
Axle specs. | FUWA ,YAHUA or BPW Brand |
Suspension | Mechanical or air supension (American or German) |
Rim | 6.5-20/8.25-22.5/9.00*22.5 /80-.0-20/8.5-20 |
King Pin | JOST 2" or 3.5" traction pin |
Support legs | JOST, FUWA or YAHUA brand 28T |
Wheelbase | 7180/6680/6260+1310+1310mm,Or other |
Steel Spring | 8/8/8, 10/10/10, 12/12/12 pieces per axle |
Ladder | Manual or hydraulic automatic |
Electrical system | 24V, 7 pin socket, One set 7-core standard Cable |
Tire | 8.25R20/8.25R16/11.00R22.5/12.00R22.5/10.00R20/11.00R20/12.00R20 |
Spare Tire Carriers | 2 pieces |
The material of Main beam | Height: 450mm-520mm, upper plate thickness is 14mm-25mm, middle plate thickness is 8mm-12mm, down plate thickness is 16mm-25mm; Material is Q345 Carbon Steel. |
Side beam | 16mm-25mm channel steel (Material is Q235 carbon steel) |
Platform plate | 5/6/7 mm Diamond Plate |
Brake | Kemi Brand of China |
Brake Chamber | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TAIYUE brand); One piece of 45L air tanks |
ABS system | optional |
Light | Tail lamp with turn signal, brake light & reflector, side lamp etc |
Tool box | 1 sets(waterproof type) |
Spare tire carrier | 1 sets(Patent type) |
Painting | Complete Chassis sand blasting to clean rust, 2 coat of anticorrosive primer, 2 coats of final paint |
Packing | Polish with wax before shipping |
Beam Bridge Dolly Trailer Features: 1. Beam Bridge Dolly Trailer is powered by Electric Motor or Diesel Generator. 2. Customize the vehicle body width and overall length according to the special requirements of customers. 3. The comprehensive performance of the whole machine can reach the intemational advanced level. 4. Easy and comfortable operation make your working a high efficiency.
