Luyi Vehicle is an experienced semi trailer supplier & truck manufacturer which provides customized solutions.

Getting heavy equipment onto a trailer without a crane on site is where a 20-ton winch changes the operation entirely. When a disabled excavator, military vehicle, or tracked machine can't drive on under its own power, the integrated winch pulls it up the mechanical two-section ramps and onto the 18.3m deck without waiting for external lifting equipment to arrive. At 2m wide with 12.00R20 tires on four-axle mechanical suspension, the trailer is built for the rough terrain access routes where self-recovery capability matters most. The mechanical folding ramps deploy without hydraulics — no power dependency, no fluid lines to maintain in field conditions. Built at LUYI Vehicle's factory with full customization on winch capacity, deck length, and ramp configuration.

Grain harvest logistics runs on speed — the faster a trailer empties at the silo, the more trips it completes per day. This European-style side tipper addresses that directly with a dual-section design: two independent 6.44m tipping sections discharge simultaneously from the side, clearing the full 13m cargo box without the alignment constraints of a rear-tipping unit. At 2.35m internal box height across a 13m x 2.55m footprint, the cargo volume handles serious harvest volumes per run. Four FUWA axles on full air suspension carry the load smoothly, and the liftable 4th axle with full-axle lift reduces tire contact and fuel burn on empty field-to-silo returns. Six Model 130 hydraulic cylinders plus one reserve power the tipping system with the force margin that dense grain loads require. Manual tarp on top protects cargo from moisture in transit. Built at LUYI Vehicle's factory.

Liquid resin has a narrow temperature tolerance during transport — too cold and viscosity rises to the point where discharge becomes slow or incomplete, compromising delivery schedules and product quality at the receiving plant. This 30m³ insulated tanker is built specifically around that requirement. The 10cm insulation layer between the 5mm steel inner tank and the stainless steel outer skin maintains cargo temperature across long transit times without active heating, protecting resin consistency from loading point to discharge. Four independent compartments allow multi-grade or multi-client loads in a single run. WABCO ABS and relay valve, JOST kingpin and landing gear — the safety and coupling components are specified to the standard that chemical logistics operators require. Built at LUYI Vehicle's factory with full customization on compartment layout and insulation specification.

Four axles on a 40m³ powder tanker means one thing in practice: better load distribution across the chassis, which directly extends the service life of both the tank structure and the running gear under the daily stress of full-load pneumatic discharge cycles. The onboard 4102 diesel engine drives a 12m³ air compressor independently from the tractor — discharge starts on the driver's schedule, not when tractor air pressure has built up through a shared system. Mechanical suspension across all four axles keeps the maintenance picture simple and field-serviceable on regional cement distribution routes. Built at LUYI Vehicle's factory with full customization on tank volume and discharge configuration.

Running containers and bulk cargo on the same trailer without switching equipment is the operational advantage this 12.5m sidewall trailer delivers. The 12 twist locks cover 20ft, 30ft, and 40ft containers at standard ISO positions, while the 0.8m sidewalls contain loose bulk cargo — grain, bagged goods, agricultural products — that a bare flatbed or skeleton chassis can't secure. BPW axles handle the load cycle consistently, and the liftable first axle on full air suspension cuts tire contact and fuel burn on every empty return leg. Aluminum alloy rims reduce rotating weight, keeping more of the legal payload available for actual cargo. The 445/65R22.5 super-single tires carry the load rating without the dual-wheel width penalty. Built and customized at LUYI Vehicle's factory.

Dump trailers that carry grain, coal dust, or loose aggregate face a problem standard open-top designs can't solve: rain and moisture during transit damages cargo and adds dead weight to the load. The hydraulically operated roof on this 3-axle tipper closes the cargo box completely for transit and opens fully at the discharge point — no manual tarping, no time lost, no moisture ingress on long hauls. At 8.8m long with a 1.8m cargo box depth, it carries a solid volume per trip. Air suspension across all three axles with a liftable first axle keeps fuel and tire costs down on empty returns. Aluminum alloy wheels cut rotating mass, JOST outriggers handle coupling reliably, and the rear hydraulic tipping system discharges fast. Built at LUYI Vehicle's factory with full customization available.

LUYI Vehicle 40ft sidewall semi trailer is designed for flexible cargo and container transport. Measuring 12.5m × 2.5m × 3.6m with a 2m-high cargo box, it uses 3-axle mechanical suspension and 12 container twist locks for secure loading. The removable sidewalls allow quick conversion into a flatbed trailer, giving fleet operators one practical trailer for different cargo requirements.

LUYI Vehicle 5 axle side tipper semi trailer features a 13.5m × 2.55m × 3.8m overall size and a 1.95m-high double-section cargo box. Equipped with air suspension, liftable first and last axles, 385/65R22.5 tires and 6 × 130 lifting cylinders, it supports efficient side unloading while helping improve stability, tire wear and operating flexibility. Custom configurations are available for different cargo and road conditions.

Container operators running mixed fleets need a trailer that earns its keep on every load, not just when the cargo type is ideal. This 12.5m flatbed covers both sides of that requirement: 12 twist locks handle 20ft and 40ft containers securely, while the open deck takes bulk cargo, steel coils, machinery, and general freight without any configuration changes. The front headboard protects cargo from forward shift during hard braking — a practical detail that prevents load movement and reduces cargo damage risk on long-haul routes. Three-axle mechanical suspension keeps the chassis serviceable anywhere the truck operates. At 2.5m wide, the trailer fits standard port gates and freight terminal access without permit complications. Built at LUYI Vehicle's factory with full customization on twist lock layout and deck dimensions.

Most container operations depend on port cranes or reach stackers to place boxes onto trailers — which means waiting. This side-lift trailer eliminates that dependency entirely. The integrated 37-ton hydraulic crane lifts 20ft and 40ft containers directly from the ground or from stacks, loads them onto the trailer, and the vehicle moves without needing any third-party lifting equipment at the pickup or delivery point. The 4102 diesel engine and hydraulic station power the entire system independently, so the operation works wherever the truck can go — not just where port infrastructure exists. Body extends from 20ft to 40ft to match the container. Built at LUYI Vehicle's factory, fully customizable on crane capacity and chassis configuration.
